ToolDraft
USD
$3350.00
Online purchases not available outside US. Please proceed to get your request for quote.
ToolDraft is a PC software package for creating 2D cutting tool drawings. It provides features to:
− Insert multiple views of a tool and tool profiles
− Dimension tool features
− Annotate drawings with text, images and drafting symbols
− Insert tables to create title blocks
− Load and save user defined drawing templates
− Export drawings as PDF and DXF
− Print drawings
Drawings can be created by importing an existing Cim3D file.
